Technical specifications
DATASHEET (PDF)
Variants: AXIS Q1728-LE 48 mm / AXIS Q1728-LE
Camera
Property description Property value
Lightfinder Lightfinder 2.0
Min illumination/ light sensitivity (Color) 0.05 lux
Min illumination/ light sensitivity (B/W) 0.01 lux
Image sensor CMOS
Image sensor size 1/1.2"
Wide dynamic range Forensic WDR
Video
Property description Property value
Max video resolution 3840x2160
Max frames per second 50/60
Electronic image stabilization Yes
Lens
Property description Property value
Focal length * 15.2 - 48.7 / 5.9-13.3 mm
Horizontal field of view * 42 - 13 / 108-49 °
Vertical field of view * 24 - 7 / 58 - 27 °
Lens mount -
Replaceable lens –
Compression
Property description Property value
Zipstream Yes
H.264 Baseline, High, Main
H.265 Yes
AV1 On
Audio
Property description Property value
Audio Support Yes
Network
Property description Property value
PoE Class 4
Wireless –
Security
Property description Property value
Signed OS Yes
Secure boot Yes
Secure keystore Secure Element (CC EAL6+, FIPS 140-3 Level 3)
General
Property description Property value
Remote focus Yes
Remote zoom Yes
Built-in IR Yes
Local storage (memory card slot) Yes
Operating temperature -40 to 60 °C
Outdoor Ready Yes
Vandal rating IK10
IP rating IP66, IP67
Designed for repaint Yes
Sustainability BFR/CFR free, PVC free
Power
Property description Property value
Power (max) 25.5 W
Power (average) 9.0 W
DC input voltage 10-28 V
