M118VG1250IR Tamron DC Auto Iris CS/CCTV Lens

SPECIFICATIONS
M118VG1250IR
Imager Size 1/1.8
Mount Type CS
Focal Length 12  -  50mm
Aperture Range F/1.4  -  360
Angle of View
(Horizontal x Vertical) 1/1.8 Wide 34.0°  x  25.5°
Tele 8.5°  x  6.4°
1/2 Wide 29.9°  x  22.4°
Tele 7.5°  x  5.6°
1/3 Wide 22.4°  x  16.8°
Tele 5.6°  x  4.2°
Focusing Range 1.0m  -  ∞
Operation Focus Manual with Lock
Zoom Manual with Lock
Iris DC Auto Iris
Back Focus(in air) 9.62mm(in air)
Wave Length Visible Light  -  Near Infrared
Operating Voltage Open 4V
Close 0.5V
Weight 130g
Operating Temperature -20°C  -  +60°C
